Deskripsi
Rated Output Power (W)
:
6500W
Battery Nominal DC Voltage
:
48Vdc
Max. PV Input DC Voltage
:
500Vdc
MPPT Voltage Range
:
90~450Vdc
Max. Charging Current
:
120A
Phase
:
Single phase
Dimension (DxWxH)
:
140 x 295 x 468mm
Net Weight
:
12kg
INPUT
:
Voltage
:
230Vac
Selectable Voltage Range
:
170~280Vac (for personal computers); 90~280Vac (for home appliances)
Frequency Range
:
50Hz/60Hz (auto sensing)
OUTPUT
:
Output Power
:
6.5kVA/6.5kW with PV+Battery; 6kVA/6kW with Battery only.
AC Voltage Regulation (Battery Mode)
:
230Vac±5%
Overload Capability
:
5s @ ≥150% load; 10s @ 110%~150% load; 100ms @ ≥200% load
Efficiency (Peak)
:
93%
Transfer Time
:
10ms (for personal computers); 20ms (for home appliances)
Waveform
:
Pure Sine Wave
BATTERY
:
Battery Voltage
:
48Vdc
Floating Charge Voltage
:
54Vdc
Overcharge Protection
:
66Vdc
SOLAR CHARGER & AC CHARGER
:
Solar Charger Type
:
MPPT
Max. PV Array Power
:
9000W
Max. PV Input Current
:
27A
Max. Solar Charge Current
:
120A
Max. AC Charge Current
:
120A
Communication Interface
:
RS232/RS485/WiFi
OPERATING ENVIRONMENT
:
Humidity
:
5% to 95% relative humidity (non-condensing)
Operating Temperature
:
-10°C to 50°C
Storage Temperature
:
-15°C to 60°C
